Specifications ( Thông số kỹ thuật )
Processor Type Intel
Processor Family Intel® Xeon® Scalable 8100/8200 series Intel® Xeon® Scalable 6100/6200 series Intel® Xeon® Scalable 5100/5200 series Intel® Xeon® Scalable 4100/4200 series Intel® Xeon® Scalable 3100/3200 series
Processor Core Available 4 to 28 core, depending on model
Processor Cache Installed 8.25 - 38.50 MB L3, depending on processor model
Maximum Memory 3.0 TB with 128 GB DDR4, depending on processor model; 6.0 TB with HPE 512GB 2666 Persistent Memory Kit, depending on processor model
Memory Slots 24 DIMM slots
Memory Type HPE DDR4 Smart Memory with optional Intel Optane Persistent Memory for HPE, depending on processor model selected. Intel Optane Persistent Memory for HPE only supported on select 2nd Generation Intel Scalable Series Processors, to include: 82xx, 62xxR, 62xx, 52xxR, 52xx series processors, and the 4215R and 4215 processors.
NVDIMM Type HPE NVDIMM-N *Only available on 1st Generation Intel® Xeon® Scalable Processors
NVDIMM Rank Single rank, NVDIMM Capacity16 GB
Drive Supported 8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD; 2 M.2 SATA SSD standard on primary riser, depending on configuration; 6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF or 2 Dual UFF rear drive optional; 20 SFF NVMe optional; NVMe support via Express Bay will limit maximum drive capacity
Network Controller HPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM, depending on model
Remote Management Software HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional; requires licenses)
System Fan Features Hot-plug redundant fans, standard
Expansion Slots 8, for detailed descriptions reference the QuickSpecs
Storage Controller 1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model
Warranty Standard Statement 3/3/3 - Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage.
Processor Name Intel, Processor Number1 or 2
Processor Speed 3.9 GHz, maximum depending on processor
Standard Memory 3.0 TB (24 X 128 GB) LRDIMM; 6.0 TB (12 X 512 GB) Persistent Memory
Security Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
Form Factor 2U
Weight (imperial) 32.6 lb,Weight (metric) 14.76 kg
Product Dimensions (imperial) 17.54 x 28.75 x 3.44 in,
Product Dimensions (metric) 44.55 x 73.03 x 8.74 cm
Intel Xeon and Intel are trademarks of Intel Corporation in the U.S. and other countries. Microsoft and Azure are registered trademarks of Microsoft Corporation in the United States and other countries. All other third-party trademark(s) is/are property of their respective owner(s)
Intel® Xeon® Gold 6426Y (16 core, 2.50 GHz, 37.5 MB L3, 185W)
DDR5 32GB RDIMM, 4800MT/s Dual Rank
Options
Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter
MegaRAID MR408i-o OCP SPDM Storage Controller
1x PSU 800W Hot Swap
